Presence controlled energy level¶

In this example energy level is selected by local information - presence information from room control panel and presence sensor. More complex scenarios might involve using a “pre-comfort” energy level controlled by building managment system / room occupancy control system. To keep the example simple, xPrecomfort := TRUE does switch the energy level from “economy” to “pre-comfort”, but doesnt effect an active energy level “comfort”. Dealing with “pre-comfort” is a bit more complex in real world applications.

Night cooling¶

Cooling down the room using cooler outdoor air is done using HeatCoolUsingOutdoorAir.

Energy lock¶

The energy lock function prevents energy consumption if window is opened. Nevertheless building protection is taken care for running the sequence controller with the related building protection setpoints. In case control actions are executed and energy is spent xBuildingProtectionActive is signalling this. The energy lock does imply an on-delay, so window needs to be open for tEnergyLockOnDelay before building protection setpoints are used. Also there is a tEnergyLockMaxTime limiting the duration of the energy lock function.

Sommer compensation¶

Sommer compensation is done shifting the setpoints (in “comfort” energy level only) using a CommandVariable to adjust setpoints.

Fast heat / cool¶

Fast heat / cool is about to bring a room the “comfort” conditions during “pre-comfort” mode because a switch to “comfort” is going to happen soon. Common use case - hotel receptionist does a checkin procedure, starting fast heat / cool right away.

Window alarm¶

Window alarm is signalled, if room is not occupied, window contact is signalling open window and night cooling does not open the window.

Manual fan control¶

Manual fan control can be done via room control panel if room is occupied.

Hints¶

Unused pins of function block instances are hidden, so refer to the function block documentation for more details.

Caveats¶

To keep complexity as low as possible this example omits the following real world application aspects worth mentioning:

• configuration missing (configuration of m_energyLevelSetpoint, m_sequenceControl etc. is not exposed on the ExampleAirConditioning1 VAR_INPUT section)

• input consistency checks (implausible measurement values, …)

• simplistic energy level selection - usually their is more complex state machinery in room control panel / building managment system / room occupancy control system

• “pre-comfort” energy level controlled by building managment system / room occupancy control system

• xError / eErrorID not computed from xError / eErrorID of function block instances used, see ExampleAirConditioning2 how to do this

• sensor / actuator process I/O not mapped (FB sensor inputs, m_windowActuator, m_valveHeat, m_valveCool, m_condensatePump, …)

InOut:

Scope	Name	Type	Initial	Comment
Input	xEnable	BOOL	TRUE	Enable
	xPresenceSetting	BOOL	TRUE	Presence signalled by room control panel
	rIdaTemp	REAL	22.0	Indoor air temperature signalled by room control panel
	usiFanStageManual	USINT (0..3)	0	Fan speed manual control requested by room control panel - 0 => off, or stage 1 .. 3
	xFanStageManual	BOOL	FALSE	Fan speed manual manual control requested by room control panel.
	xPrecomfort	BOOL	FALSE	Enables the “pre-comfort” energy level.
	xFastHeatCool	BOOL	FALSE	Enables the fast heat / cool mode.
	xPresence	BOOL	TRUE	Presence signalled by presence sensor
	rOdaTemp	REAL	10.0	Outdoor air temperature
	xWindowOpen	BOOL	FALSE	Window contact signalling open window.
	xNightCooling	BOOL	FALSE	Enable night cooling
	xEnergyLock	BOOL	FALSE	Enable energy lock
	tEnergyLockOnDelay	TIME	TIME#10s0ms	Energy lock on-delay
	tEnergyLockMaxTime	TIME	TIME#10m0s0ms	Energy lock maximum duration
	xSummerCompensation	BOOL	FALSE	Enable summer compensation
	xReset	BOOL	FALSE	Reset
	itfDateTimeProvider	Util.IDateTimeProvider	Globals.g_dtpDateTimeProvider	Source for the current date and time information in milliseconds since 1.1.1970 00:00:00.000
Output	eLevel	EnergyLevel		Energy level
	eMode	HeatCoolOperationMode		Operation mode.
	xWindowAlarm	BOOL		Window alarm
	xBuildingProtectionActive	BOOL		There are control actions / energy consumption to keep indoor air temperature in the building protection setpoint range.
